PA 2200 - Polyamide 12

EOSArticle Number: 9012-0014

Balanced part property profile characterized by strength, rigidity and good chemical resistance.

Suitable for FORMIGA P 110 Velocis, EOS P 396, EOS P 770 and EOS P 500.

Description

The property profile of durable white parts made from PA 2200 is very balanced: such parts are characterized by strength, rigidity and good chemical resistance.

Typical mechanical properties in xy print direction
Tensile modulus 1650 MPa
Tensile strength 48 MPa
Strain at break 18%

Thermal properties
Melting temperature (20°C/min) 176°C

Physical properties
Density 930 kg/m³

This cost-efficient general-purpose material is suitable for a variety of applications, including functional prototypes and qualified series production parts from several industries.

The data corresponds to our knowledge and experience at the time of publication. They do not on their own represent a sufficient basis for any design, neither do they provide any agreement about or guarantee the specific properties of a product or part or the suitability of a product or part for a specific application. It is the responsibility of the producer or customer of a part to check its properties as well as its suitability for a particular purpose. This also applies regarding the consideration of possible intellectual property rights as well as laws and regulations. The data are subject to change without notice as part of EOS` continuous development and improvement processes.
