PA 603-CF

33% Carbon-Fiber-Filled Nylon 12 optimized for a smooth surface finish without sacrificing feature details. It has a high-detail black surface finish, good stiffness and mechanical properties. It also has warping resistance at elevated temperatures.

Typical mechanical properties
Tensile modulus 7900 MPa
Tensile strength 85 MPa
Elongation at break 4 %
Thermal properties
Heat deflection temperature (1.82 MPa) 173 °C
Heat deflection temperature (0.45 MPa) 179 °C
Physical properties
Sintered Density 1,1 g/cm³

• High impact sports equipment
• High performance racing applications
• Wind tunnel model testing Ideal for applications requiring the highest stiffness and heat resistance

Product Summary

Suitable for P396, P770 and roller based systems
Carbon fiber-filled Nylon 12 with ESD and high mechanical properties.
Item No 9015-0012
Contact sales team
