PA 615-GS

ALMArticle Number: 9015-0008

Glass sphere filled material for improved dimensional stability with increased stiffness and part surface finish.

Contact sales

Description

50% Glass-Sphere-Filled Nylon 12 optimized for easy processing and as a drop-in replacement for comparable Glass-Sphere-Filled Nylon 12’s. It has smooth surface finish, good stiffness and mechanical properties , and high recyclability.

Typical mechanical properties
Tensile modulus: 5910 MPa
Tensile strength: 38 MPa
Elongation at break: 2%

Thermal properties
Heat deflection temperature (1.82 MPa): 134 °C
Heat deflection temperature (0.45 MPa): 179 °C

Physical properties
Sintered Density: 1,49 g/cm³

Automotive engine components
Mold and tooling applications
Complex geometries requiring accuracy and feature resolution
Ideal for rugged applications requiring stiffness at elevated temperatures

The data corresponds to our knowledge and experience at the time of publication. They do not on their own represent a sufficient basis for any design, neither do they provide any agreement about or guarantee the specific properties of a product or part or the suitability of a product or part for a specific application. It is the responsibility of the producer or customer of a part to check its properties as well as its suitability for a particular purpose. This also applies regarding the consideration of possible intellectual property rights as well as laws and regulations. The data are subject to change without notice as part of EOS' continuous development and improvement processes.
